Manuals
English operation & maintenance manuals with shipment. Other languages on request.
AN-45 · 45 HP Compact Tractor
Orchard-ready compact tractor for small farms and plantations.
Compact Series
4WD
Export Spec
Factory Direct
FOB / CIFTrade terms
QCFactory inspection
PartsStarter kits
OEMBranding options
45 HPEngine power
4WDStandard drive
≥ 900 kgLift capacity
Cat. I3-point hitch
45 HP
Exterior · Side view
▶
Product walkaround video · Replace with real media
Model Overview
The AN-45 is AgriNova's best-selling compact export tractor. Narrow stance options, responsive steering, and a practical 4WD drivetrain make it a strong fit for orchards, vegetable farms, and light transport duties.
Export note: Specifications below are typical configurations. Final PI may vary by engine option, tires, cabin, and destination requirements.
AG
Agile footprint
Compact dimensions for orchard rows, greenhouse lanes, and small plots.
4W
4WD traction
Confident grip on wet soil, slopes, and uneven plantation tracks.
PT
PTO versatility
540/1000 rpm options for rotary tillers and light implements.
OP
Operator options
ROPS, canopy, or cabin packages for climate and safety needs.
EX
Export packing
Protective packaging designed for ocean freight and multi-unit loading.
SV
Service access
Straightforward layout for routine maintenance by local technicians.
Replace with dimension drawing / real photo
Wheelbase1,750 mm
Min. ground clearance300 mm
Min. turning radius3.2 m
Operating weight≈ 1,650 kg
Fuel tank38 L
Spare parts
Recommended starter kits for wear items—filters, belts, seals, and common consumables.
Dealer help
Remote technical support for configuration questions and service troubleshooting.
Technical Data
AN-45 Specifications
Grouped specs for engine, drivetrain, hydraulics, and dimensions.
Engine & Drive
| Engine power | 45 HP |
|---|---|
| Engine type | 3-cylinder diesel, water-cooled |
| Rated speed | 2400 rpm |
| Drive | 4WD |
| Clutch | Dual stage |
Transmission & PTO
| Transmission | 8F+2R / optional shuttle |
|---|---|
| PTO | 540 / 1000 rpm |
| Steering | Hydraulic power steering (opt.) |
Hydraulics & Hitch
| Hydraulic lift capacity | ≥ 900 kg |
|---|---|
| Three-point hitch | Category I |
| Hydraulic outlets | Optional multi-way valves |
Dimensions & Weight
| Wheelbase | 1,750 mm |
|---|---|
| Min. ground clearance | 300 mm |
| Min. turning radius | 3.2 m |
| Tire size (F/R) | 6.00-16 / 9.5-24 |
| Fuel tank | 38 L |
| Operating weight | ≈ 1,650 kg |
Contact us for a formal datasheet PDF with the exact configuration you need.
Configuration
Option Packages
Start from a package, then fine-tune tires, cabin, and implements.
Essential
Standard export
- 4WD chassis
- Basic lighting
- English manual
- Tool kit
Orchard Pro
Popular package
- Low-profile options
- Canopy / ROPS
- Rotary tiller ready
- Orchard tire options
Dealer Launch
Market entry
- Spare-parts starter kit
- Branding options
- Training materials
- Container loading plan
Where It Works
Ideal Applications
Orchard & vineyard
Narrow work between tree rows and vines.
Vegetable & small farm
Seedbed prep and light transport on small plots.
Greenhouse support
Compact access for protected cropping operations.
Yard logistics
Trailer and material movement around the farm.
Matched Tools
Compatible Implements
Ship tractor and tools together to simplify first stocking for dealers.
Rotary tiller
1.2–1.6 m
Light plow
2–3 disc
Farm trailer
Single axle
Mower*
PTO driven
Logistics & Trade
Export Package
Shipping
- 20' / 40' HQ container guidance
- Mixed tractor + implement loading
- Protective export packing
- RO-RO discussion for large units
Documents
- Commercial invoice & packing list
- Bill of lading coordination
- Certificate support as required
- English operation manual
After-sales
- Warranty framework for export
- Spare-parts ordering channel
- Remote technical support
- Service training materials
FAQ
AN-45 Questions
Is AN-45 suitable for orchard rows?
Yes—compact dimensions and optional low-profile packages are designed for orchard and plantation work. Share your row width for confirmation.
What implements pair best with AN-45?
Rotary tillers, light plows, single-axle trailers, and selected PTO tools. See the compatible implements section.
Can I order OEM branding?
OEM/ODM options are available for qualified orders. Mention branding needs in your inquiry.
Ready to Quote AN-45?
Tell us destination port, quantity, and preferred options—export sales will respond within one business day.
